  /    /  PRESS BRAKE, STEEL FABRICATION  /  SINGLE SERVO MOTOR CNC PRESS BRAKE- HG-12532NT

SINGLE SERVO MOTOR CNC PRESS BRAKE- HG-12532NT


GHBM

GHBM series SINGLE SERVO MOTOR CNC Press Brake has two hydraulic cylinders with electro hydraulic servo valve. Deflection can be compensated by hydraulic vaulted back-off system. Back gauge mechanism can control several back gauge axes. Its frame is welded with steel plate and is treated with annealing. Hydraulic system adopts integrated control system and imported ring seals. CNC Control DELEM DA-53T includes English menu display control. CNC system DA-53T system made in Delem Company in Holland. The Press Brake is a punch quick mounting device. It can also be equipped with mould fixture according to customer’s requirement.

Quick info

Categories: ,
GET A QUOTESpecs pdf download

Description

SINGLE SERVO MOTOR CNC PRESS BRAKE MACHINE (4 Axis + CNC Crowning)
Model No: HG-12532NT (125Ton x 3200)
Brand Name: “HGBM”
With DELEM DA-53T CONTROL SYSTEM
Nominal Force: 1250 KN
Bending Length: 3200mm
Ram stroke Length: 200 mm
Max. Opening Height (without clamping): 530 mm
CNC Axes: Y1, Y2, X, R, V
Throat Depth: 400 mm
Main Servo Motor Power: 11 KW
Ram Approaching Speed: 150 mm/s
Ram Bending Speed: 10 mm/s
Ram Returning Speed: 130 mm/s
X Axis Stroke: 600 mm
X Axis Max. Speed: 350 mm/s
X axis Positioning Accuracy: Ø0.05 mm
R Axis Stroke: 150 mm
R Axis Max. Speed: 150 mm/s
R axis Positioning Accuracy: Ø0.05 mm
Distance Between Columns: 2750 mm
Machine Dimension (L x W x H): 3500 x 1600 x 2750mm
Weight: 8000 kg. (8 Ton)
Brand New: China
  • Synchronous double cylinders control system adopts electric-hydraulic servo control to achieve high definition of control, bending and reorientation and therefore it becomes possible for machine's partial load control.
  • Hydraulic automatic compensatory crowing system avoids the infection that the shape-changed ram affects the quality of working goods during bending process. The compensatory quality is adjusted by digital control system automatically. It is accurate and convenient.
  • Full function back gauge may control several back axis.
  • The machine adopts a construction of entire welding and backfire treatment with the result of well rigidity and high strength and machining accuracy.
  • The hydraulic system adopts compacted control system with fewer pipes. The import seal rings have promoted the machine stability. It looks very good.
  • With the preparation of detachable up model, man can mount a certain length of model according to the requirement of working goods in order to at the requirement of special good. The upper model adopts safe channel construction (EUR standard)
  • Digital control system adopts Holland-made DA-53T system of Delem Company.
  • On each side of machine body there is a C-shape plate with high accurate roster. That avoids the affection of bending accuracy when the machine is shape-changed
  • It is leakage-free because of all seal goods are imported completely.
