HYDRAULIC SECTION BENDER W24Y-1000


PROTECH



MACHINE DESCRIPTION:

This machine is driven by Hydraulic pressure. It is suitable for rolling the angle into the round shape. The machine is reliable to operate with various functions and is an ideal bending machine that’s adjustable and able to deal with different types of materials and specifications only by recombining the die settings.









Quick info

SKU: 9911081057 Categories: , ,
GET A QUOTESpecs pdf download

Description

HYDRAULIC SECTION BENDER
Model NoW 24 Y – 1000
Brand Name“WEIDA”
AnglePipe
Max. Dimension of the material75 x 75 x 5ø 70
Min. Bending Diameter700ø 700
Main MotorY100LA 4kw. 1500rpm
Motor of Hy. SystemY100LA 2.2kw 1500rpm
Motor of Hy. SystemPV2R1-10
Model of reducerBLB3-50-3kw 1:50
Speed of rollerAbout 8rpm
Model Size (L x W H)1320 x 950 x 1270 mm
PhaseThree (380 V) Hz 50.60
Weight1950 kg









  • Right Hydraulic Canister – Controlling the right pressure roller up and down
  • Left Hydraulic Canister – Controlling the left pressure roller up and down
  • Left guiding set – Guiding the work piece.
  • Left Downward roller
  • Upper roller
  • Right Down downward roller
  • Main Motor (Y100L4/3)
  • Vee-pulley reducer auxiliary
  • Double cycloid reducer
  • Gear reducer
  • Hydraulic Cylinder
  • Hydraulic Motor Y100L4/2.2 kw
  • Hydraulic Station
