Carif is a mechanical company in the band saws market since 1948. Today it is a modern and flexible reality, which exports its products all over the world.
MACHINE DESCRIPTION :Â
Extremely robust Semi-Automatic Band Saw designed to cut medium/big dimension equipped with 2 speed motor 2.4Kw. Ø330 mm; 450x240h mm. It is used to cut many kinds of metal materials like carbon structural steel, low alloy steel, high alloy steel, special alloy steel and stainless acid resistant steel.
WORKING PRINCIPLES:
Band Saw is a precision cutting tool. The working principle of a band saw machine cuts material to desired shape. Cuts are made by a blade that has long sharp teeth continuously rolling in loop through material.
| HYDRAULIC BAND SAW SEMI AUTOMATIC | ||
|---|---|---|
| Machine No. | 450-BSA | |
| Brand Name | CARIF | |
| CUTTING CAPACITY | ||
 | 90° | 330 mm |
| -45° | 260 mm | |
| 45° | 280 mm | |
| 60° | 170 mm | |
 | +90° | 320*/280 mm |
| -45° | 220 mm | |
| +45° | 250 mm | |
| +60° | 150 mm | |
 | +90°▲ | 450 x 240 mm |
| -45° | 310 x 100 mm | |
| +45° | 270 x 240 mm | |
| +60° | 170 x 125 mm | |
 | +90° (OPTIONAL) | 450 x 240 mm |
 | 3660 x 34 x 1.1 mm | |
 | 2.4-0.75-0.09 KW | |
 | 32-64 m/1’ | |
 | 450 mm | |
| : OPTIONAL | 500 mm | |
 | B L H*(Bow up and Bow down) | 2000 mm 1000 mm 2000/ 1550 mm |
| Weight | 2 kg |
|---|---|
| Dimensions | 3 × 4 × 5 cm |
